Supermicro A2SAP-L-O
Up to 8GB 1866MHz DDR3L Non-ECC SO-DIMM in 1 socket 1 M.2 B-Key 2242/3042, 1 Half size Mini-PCI-E, 1 SATA 3.0 2 USB 3.0 ports (rear), 2 USB 2.0 ports (via headers), 2 COM ports (via headers) Intel® Atom processor E3930 (6.5W, 2C) Intel® Goldmont microarchitecture 14nm System-on-Chip Dual Gigabit Ethernet LAN ports via Intel® i210AT 1 HDMI, 1 48-bit LVDS, Intel® HD Graphic 2 independent displays Supports 12V DC power input
We also offer six months of free collocation in our TIER III data center.
Components are not the end — ask us for a custom server configuration. We will design the server, assemble it, expertly set it up, and provide extended or NBD warranty.
| Product code | 200.152227 |
|---|---|
| Part number | MBD-A2SAP-L-O |
| EAN | 672042300198 |
| Manufacturer | Supermicro |
| Availability | ETA 3 weeks |
| Warranty | 36 months |
| Weight | 1 kg |
Server system integrator & worldwide shipping
Personal approach and tailor-made servers
NBD warranties & cross-shipping
Private cloud infrastructure
Pre-sales & After-sales support
Detailed information
Motherboards
Supermicro motherboards support the latest generation Intel and AMD processors, memories and offer the most advanced technologies in the IT field – NVMe, M.2, 10GbE network ports. Thanks to their high scalability and a wide choice of form factors, the boards can fulfill the needs of even the most demanding customers. Supermicro offers the broadest selection of servers designed for industrial use, which is reflected in the overall quality of the boards. Materials that guarantee a long lifespan are used for manufacturing Supermicro motherboards, thanks to which a minimal failure rate is achieved. Supermicro motherboards go through a generational exchange approximately once every seven years, which guarantees long support by the manufacturer. Each Supermicro motherboard also allows free installation of specialized software for basic system monitoring.
The purchase of NBD warranty of your own choice is a matter of course, which minimizes service outages even in cases that cannot be predicted. Contact our sales department for more information. Standard NBD warranties are offered for 3 or 5 years.
Product specifications
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Parameters
| Dimensions | 3.9" x 2.8" |
|---|---|
| CPU manufacturer | Intel |
| Socket | SoC Intel |
| Processor generation | Intel 1.gen |
| Number of CPUs | 1 |
| Max. DIMM slots | 1 |
| Max. frequency | 1866 MHz |
| Internet connector | RJ45 |
| NIC speed in Gbps | 1 Gb |
| M.2 count | 1 |
| DVI port | No |
| VGA port | No |
| HDMI port | Yes |
| TDP (W) | 6.5 |
| Processor series | TypProc Atom SoC |
