AIC RSC-3ET-35X - XE1-3ET00-15
3U 16x 3.5" hot-swap bays, tool-less 3.5" and 2.5" HDD tray, 1200W CRPS redundant power supply Platinum, 4x 2.5" internal 7mm top plate, 2x 2.5" hot-swap OS, rail, 3U16 SAS 12G expander controller on backplane (35X series)
We also offer six months of free collocation in our TIER III data center.
| Product code | 202.179558 |
|---|---|
| Part number | XE1-3ET00-15 |
| Manufacturer | AIC |
| Availability | On demand |
| Warranty | 36 months |
| Weight | 34 kg |
Server system integrator & worldwide shipping
Personal approach and tailor-made servers
NBD warranties & cross-shipping
Private cloud infrastructure
Pre-sales & After-sales support
Detailed information
AIC Servers
AIC's offers heavy-duty EMI-RFI-resistant industrial computer enclosures. Their scalable and cost-effective enclosure solutions encompass server and storage enclosures in a variety of form factors and specifications. AIC enclosures are designed to support the latest technology platforms in the market today, ensuring maximum compatibility with products from other component vendors.
Invest in Certainty
AIC, with over 30 years of experience, offers unmatched flexibility and scalability in the market. Its wide range of products allows maximum customization according to individual customer needs. With the trust the company places in its solutions, it provides extended warranties on its products for 5 years and more. The combination of efficient and modern design positions AIC at the forefront of the market, enabling it to quickly gain recognition in the mainstream.
-
- General information
Dimensions (W x D x H) mm : 430 x 680 x 133
inches : 17 x 26.8 x 5.2Industry Standard EIA-RS310D Material Heavy-duty preplated SGCC cold-rolled steel Color Front Panel : Black Cooling 3 x 80x38mm PWM & low-power consumption hot swap fans Power Supply 1200W 1+1 redundant PSU PMBus 1.2 80+ Platinum Expansion Slots 7 Front Panel System power on/off, System reset and 2x USB 3.0 ports LED Indicators Power, LAN, Drive and Alert System Board 12”(W) x 13”(D) E-ATX/SSI EEB 3.6 compliant MB Drive Bays External:
16x 3.5" SAS/SATA Hot-Swap
Internal:
4x 2.5" 7mm Top Plate
2x 2.5" Hot-Swap OSBackplane 1 x 16-port 12Gb SATA/SAS backplane with 28-PHY expander chip and 3 SFF-8643 connectors Storage Temperature 0ºC (32ºF) ~ 50ºC (122ºF) Humidity 5% ~ 95% non-condensing Weight kgs : 34
lbs : 75Packaging Dimensions (W x D x H) mm : 645 x 835 x 268
inches : 25.4 x 32.9 x 10.6Cubic Feet 6.03 Container Load Quantity 20’ 170
40’ 355
40’ H 405Mounting Standard 28” tool-less slide rail
Parameters
| Size in U | 3 |
|---|---|
| Depth (mm) | 680 |
| CPU manufacturer | None |
| Socket | None |
| HDD disks | 6 |
| 2.5" Drive bays | 6 |
| 3.5" Drive bays | 0 |
| NVMe slots | 0 |
| Total amount of PCIe | 7 |
| OCP/AIOM | 0 |
| Power (W) | 1200 |
| Efficiency certification | Platinum |
