AIC RSC-2ET3 - XE1-2ET01-09
2U 12x 3.5"/2.5" SAS/SATA hot-swap (EOB BP) Chassis, 2x 2.5" 7mm SATA hot-swap, 3x 8038 fan, Acbel 1200W redundant power supply Platinum, Low profile rear panel, 28" slide rail, w/o bezel
We also offer six months of free collocation in our TIER III data center.
| Product code | 202.179438 |
|---|---|
| Part number | XE1-2ET01-09 |
| Manufacturer | AIC |
| Availability | On demand |
| Warranty | 36 months |
| Weight | 24 kg |
Server system integrator & worldwide shipping
Personal approach and tailor-made servers
NBD warranties & cross-shipping
Private cloud infrastructure
Pre-sales & After-sales support
Detailed information
AIC Servers
AIC's offers heavy-duty EMI-RFI-resistant industrial computer enclosures. Their scalable and cost-effective enclosure solutions encompass server and storage enclosures in a variety of form factors and specifications. AIC enclosures are designed to support the latest technology platforms in the market today, ensuring maximum compatibility with products from other component vendors.
Invest in Certainty
AIC, with over 30 years of experience, offers unmatched flexibility and scalability in the market. Its wide range of products allows maximum customization according to individual customer needs. With the trust the company places in its solutions, it provides extended warranties on its products for 5 years and more. The combination of efficient and modern design positions AIC at the forefront of the market, enabling it to quickly gain recognition in the mainstream.
-
Dimensions
(W x D x H)430 x 680 x 88 [mm] Industry Standard EIA-RS310D Material Heavy-duty preplated SGCC cold-rolled steel Color (Front Panel) Black Cooling 3x 80x38mm hot swap fans Power Supply 1200W 1+1 redundant PSU Platinum Expansion Slots 7x Low Profile Front Panel System power on/off, System ID, System reset and 2x USB 3.0 ports LED Indicators Power, LAN, Drive and Alert
-
System Board 12” x 13” (E-ATX/SSI EEB 3.6 compliant MB) Drive Bays
(External)12x 3.5" Hot-Swap
2x 2.5" SATA Hot-Swap (7mm)Backplane 12x 3.5" SAS/SATA hot-swap (EOB BP) Storage Temperature 0 ºC ~ 50 ºC Humidity 5%~95% non-condensing Gross Weight 23.5 kg Mounting (Standard) 28” tool-less slide rail
Parameters
| Size in U | 2 |
|---|---|
| Depth (mm) | 680 |
| CPU manufacturer | None |
| Socket | None |
| HDD disks | 14 |
| 2.5" Drive bays | 2 |
| 3.5" Drive bays | 12 |
| NVMe slots | 0 |
| Total amount of PCIe | 0 |
| OCP/AIOM | 0 |
| Power (W) | 1200 |
| Efficiency certification | Platinum |
